SMC Type Pneumatic Speed Regulating Throttle Valve Connector AS2201F-02-06S

Product Description:

Many models feature a scale window for numerical flow management, with some including a vernier for precise 1/4-scale settings. The scale is visible from 360 degrees, improving accessibility for inspection and maintenance.

The push-to-lock mechanism enhances needle valve locking operation, making setup faster and reducing setup time and potential errors. Some models also have a larger knob diameter (approximately twice as large) for easier adjustment.

The compact design saves space, and some models achieve weight reduction of about 27%.

Tube insertion and removal are facilitated with reduced insertion force (by up to 30%) and withdrawal force (by up to 20%) while maintaining pull-out strength. The 360° free orientation piping capability (in elbow/universal types) allows for flexible installation.

Constructed with metal bodies (e.g., zinc alloy) or specific materials for standard use, with some offering stainless steel for corrosion resistance. Non-electrolytic nickel plating is standardized for some components. Options include cleanroom (low-dust generation) and corrosion-resistant models.

Certain variants combine a speed control valve with other functions, such as a residual pressure release valve (for one-button exhaust) or a pilot-operated check valve (for cylinder speed control and temporary intermediate stopping).

Applications:

SMC's AS series speed control valves are primarily utilized for regulating the speed of pneumatic actuators by adjusting the flow of compressed air.

They are specifically designed for low-speed control applications, catering to cylinder movement speeds ranging from 1 mm/s to 50 mm/s or 50 mm/s to 150 mm/s.

The valves are commonly used for general speed regulation in pneumatic systems, functioning as meter-out flow control by throttling the exhaust port in one direction while allowing unrestricted flow in the opposite direction via a built-in check valve. This feature facilitates convenient and consistent speed adjustment.

These valves are ideal for applications necessitating compact and efficient components due to their space-saving and lightweight design, making them suitable for use in compact machinery and systems where optimal use of space is vital.

In addition to general applications, specialized versions of the valves are available for use in specific environments such as cleanrooms to minimize dust generation and in environments where corrosion-resistant materials are required.

I trust this translated and summarized information enhances your understanding of the SMC AS series speed control valves. Should you require more detailed information about a particular model or application, please don't hesitate to inquire further.

Support and Services:

Our Pneumatic Pipe Fittings come with comprehensive Product Technical Support and Services to address any issues or queries you may have. Our team of experts is available to provide guidance on installation, troubleshooting, and maintenance of the fittings to ensure optimal performance. Additionally, we offer training programs and resources to help you make the most of your pneumatic system.

Packing and Shipping:

Product Packaging:

Our pneumatic pipe fittings are carefully packaged to ensure safe delivery. Each fitting is individually wrapped in protective material to prevent scratches and damage during transit. The fittings are then placed in a sturdy cardboard box with ample cushioning to further protect them during shipping.

Shipping Information:

We offer fast and reliable shipping for our pneumatic pipe fittings. Orders are typically processed within 1-2 business days. Depending on your location, shipping times may vary but we strive to deliver your fittings in a timely manner. Once your order has been shipped, you will receive a tracking number to monitor the status of your delivery.
