M50 Diaphragm Repair Kit For Turbo SQP50 FP55 SQM50 M50+M25 2'' Pulse Valve Membrane

Product Description:

Sealing and Opening
The diaphragm achieves rapid valve port closing (sealing) and opening (releasing compressed air) through elastic deformation:
- Closed state: It tightly adheres to the valve seat, utilizing its elasticity and air pressure difference to prevent air leakage and maintain system pressure.
- Open state: Upon receiving a control signal, it deforms instantly, opens the valve port, and enables compressed air to create a pulse jet.

Energy Transfer
The diaphragm's immediate action directly impacts the intensity and speed of the blowing airflow. Its response speed (in milliseconds) influences the ash cleaning efficiency and compressed air utilization rate.

Thickness and Size
The thickness typically ranges from 1-3mm (adjusted based on pressure levels), and the size must precisely match the pulse valve body (e.g., diameters of 50mm, 65mm). Deviations may lead to sealing failures or movement issues.

Temperature Resistance Range
- Conventional nitrile rubber (NBR): -20℃ to 80℃, suitable for normal temperature and dry conditions.
- Fluororubber (FKM): -20℃ to 200℃ (some models can reach 260℃), ideal for high temperatures and corrosive environments like the chemical industry or waste incineration.
- Silicone rubber (VMQ): -60℃ to 200℃, with excellent low-temperature resistance, suitable for cold regions.

Pressure Resistance Performance
The diaphragm should endure working pressures of 0.4-0.7MPa (special models can handle higher pressures). It must not experience permanent deformation over prolonged pressure exposure to ensure reliable sealing.

Service Life
In standard conditions, high-quality diaphragms boast a fatigue life exceeding 1 million cycles. Frequent movement or harsh environments such as dust wear or chemical corrosion can reduce their lifespan.

M50 Diaphragm For Turbo FP55 FM55 Pulse Valve

The following M50 + M25 diaphragm repair kits are designed to replace 2'' Turbo FP50, FM50, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65 valves or assist the work of the dust collector, and are designed to increase your satisfaction with the system and increase productivity. That is suitable for dust collector applications, in particular for reverse pulse-jet filter cleaning of filter bags, cartridges, envelope filters, ceramic filters and sintered metal fibre filters. Designed for strength and reliability, every part of each diaphragm kit is made of premium materials. Check out the full list below to find the product that's right for you, if you have any question and doubts, pls feel free to let us know.

Overall Dimension of M50+M25 Diaphragm Kit For 2'' Turbo Pulse Valve:

Product Details of M50 Diaphragm For Turbo FP55 FM55 Pulse Jet Valve:

Available Models of Diaphragm Repair Kits For Turbo Pulse Valves:

Applications:

TURBO Pulse Valve Diaphragm is a high-quality product suitable for various applications and scenarios due to its durable construction and reliable performance. This product is essential for maintaining the efficiency and functionality of pulse valves in different industrial settings.

The TURBO Pulse Valve Diaphragm is perfect for use in industries that require a working pressure range of 0.4-0.7MPa, making it ideal for applications where consistent performance is crucial. The diaphragm is made from high-quality Fluororubber (FKM), which can withstand temperatures ranging from -20 ℃ to 200 ℃ (some models can reach 260 ℃). This feature makes it suitable for use in high-temperature and corrosive environments, such as chemical and waste incineration facilities.

Additionally, the TURBO Pulse Valve Diaphragm comes in a sleek black color, adding a professional touch to the equipment it is used with. It is a versatile product that can be used with various pulse valves, making it a must-have for maintenance and repair tasks. The product is CE certified, ensuring its quality and reliability.

Whether you need diaphragm repair accessories, Shockwave Diaphragm Kit, or a Maintenance Kit, the TURBO Pulse Valve Diaphragm is a perfect choice. It has a minimum order quantity of 1, and the price is negotiable, making it accessible for both small-scale and large-scale operations. The packaging details include a carton, ensuring safe delivery of the product.

With a delivery time of 1-7 work days after payment and flexible payment terms such as T/T, Western Union, and Paypal, acquiring the TURBO Pulse Valve Diaphragm is convenient and hassle-free. The product has a supply ability of 5000 pieces per month, ensuring a steady availability for your industrial needs.

Packing and Shipping:

Product Name: Pulse Valve Diaphragm

Description: High-quality diaphragm designed for pulse valves.

Package Contents: One pulse valve diaphragm

Material: Durable rubber

Shipping Method: Standard shipping

Shipping Time: 3-5 business days
